Body:

304 Series Stainless Steel

Body：

Natural

Mandrel:

302 Series Stainless Steel

Mandrel：

Natural

D

L

dk

k

dm

RIVET SIZE

PART NUMBER

RIVET LENGTH

GRIP RANGE

HEAD DIA

HEAD HEIGHT

MANDREL DIA

HOLE SIZE (DRILL)

Shear (KN)

Tensile (KN)

MAX.

MIN-MAX

MAX.

MAX.

Ф

MIN.

MIN.

4.8 (3/16")

BBMC-0606

20.0

3.17-8.41

8.5

2.2

3.1

4.9-5.1

5.8

4.1

BBMC-0608

26.2

3.17-12.22

5.8

4.1

6.4 (1/4")

BBMC-0808

26.4

3.17-12.07

10.1

2.4

4.1

6.7-7.0

10.5

8.2
