Body:

302 Series Stainless Steel

Body：

Natural

Mandrel:

302 Series Stainless Steel

Mandrel：

Natural

D

L

dk

k

dm

RIVET SIZE

PART NUMBER

RIVET LENGTH

GRIP RANGE

HEAD DIA

HEAD HEIGHT

MANDREL DIA

HOLE SIZE (DRILL)

Shear (KN)

Tensile (KN)

MAX.

MIN-MAX

MAX.

MAX.

Ф

MIN.

MIN.

4.8 (3/16")

BBN-4.8×10.0

18.2

1.58-6.85

10.2

2.3

3.1

4.9-5.1

6.0

4.5

BBN-4.8×14.0

24.6

1.58-11.09

6.0

4.5

6.4 (1/4")

BBN-6.4×14.0

25.3

2.04-9.52

13.5

2.9

4.1

6.7-7.0

10.5

8.2

BBN-6.4×20.0

35.6

2.04-15.87

10.5

8.2
